To access the Digital Announcement Trunk (DAT card) via DISA, add the following programming.
DESCRIPTION DATA
Assign a Digital Announcement Trunk card
number to the required LEN.
NOTE 1: The Digital Announcement Trunk
card number must be assigned to the
first LEN (Level 0), the third LEN
(Level 2), the fifth LEN (Level 4) and
the seventh LEN (Level 6) of each
LT slot.
(1)
(2)
000-763: LEN
EB002-EB127: Digital Announcement
Trunk Card No.
For PIM0/1 : EB002-EB031
For PIM2/3 : EB032-EB063
For PIM4/5 : EB064-EB095
For PIM6/7 : EB096-EB127
NOTE 2: EB000 and EB001 are dedicated
to built-in Digital Announcement
Trunk of the MP card.
Assign a Digital Announcement Trunk card
number to the required LEN.
[Series 3200 R6.2 software required]
NOTE 1: The Digital Announcement Trunk
card number must be assigned to the
first LEN (Level 0), the third LEN
(Level 2), the fifth LEN (Level 4) and
the seventh LEN (Level 6) of each
LT slot.
(1)
(2)
XX ZZZ: LEN
XX : 00-59: FP No.
ZZZ: 000-127: Port No.
EB002-EB127: Digital Announcement
Trunk Card No.
For FP No. 00 : EB002-EB031
For FP No. 01 : EB032-EB063
For FP No. 02 : EB064-EB095
For FP No. 03 : EB096-EB127
NOTE 2: EB000 and EB001 are dedicated
to built-in Digital Announcement
Trunk of the MP card.
Assign Service Restriction Class A for Digital
Announcement Trunk access to the required
ID Code Pattern number.
•
(1)
(2)
Y=12
0000-2999: ID Code Pattern No. assigned
by CM2A Y=00-09
00-15 : Service Restriction Class A
Allow Digital Announcement Trunk access in
Service Restriction Class A assigned by
CM2A Y=12.
•
(1)
(2)
Y=33
00-15: Service Restriction Class A as-
signed by CM2A Y=12
1 : Allow
To record and replay a message from an out-
side user, assign the Digital Announcement
Trunk access code, respectively.
•
(1)
(2)
Y=0-3 Numbering Plan Group 0-3
X-XXXX: Access Code
A100: Record
A101: Replay
START
CM10
CM14
CM2A
CM15
CM20
END
DIRECT INWARD SYSTEM ACCESS (DISA)
To Next Page
