– 316 – NWA-008845-001 Rev.5.0
32ch1006.fm
DESCRIPTION DATA
Assign the ID Code Development number for
DISA.
•
(1)
(2)
Y=A0
2: DISA Code
0-9: ID Code Development No. 00-09
Assign the ID Code for DISA. •
(1)
(2)
Y=00-09 ID Code Development No. 00-09
X-XX...XX: ID Code for DISA
(Maximum 16 digits)
0000-2999: ID Code Pattern No.
Assign the purpose of ID Code. •
(1)
(2)
Y=10
0000-2999: ID Code Pattern No.
2: Validate the ID Code entered from trunks
Assign Service Restriction Class A assigned
by CM15 Y=134 to the ID Code Pattern num-
ber.
•
(1)
(2)
Y=12
0000-2999: ID Code Pattern No.
00-15 : Service Restriction Class A
Specify the setting station of Manual Call For-
warding set by DISA, if required.
If the station number is set by this command,
Call Forward setting is not available for the
other stations.
•
(1)
(2)
Y=16
0000-2999: ID Code Pattern No.
X-XXXXXXXX: Station No.
NONE : All stations
A
CM2A
END
DIRECT INWARD SYSTEM ACCESS (DISA)
CALL FORWARDING SET BY DISA
To Next Page
