DESCRIPTION DATA
Specify the ring frequency of the D
term
.
[Series 3200 R6.1 software required]
•
(1)
(2)
Y=40
00-63: Tenant No. assigned by CM30
Y=01/CM12 Y=04
See the table below.
NOTE: This data is effective only for D
term
Series i.
When using Electra Terminal/D
term
Series III/Elite Terminal/D
term
Se-
ries E, using D
term
Series i with Se-
ries 3100 software or before, or
when accommodating D
term
Series i
in TDM based Remote PIM, the sec-
ond data is fixed to 1.
Disable the ringing on each line/extension key
of a D
term
, if required.
Refer to DELAYED RINGING, when provid-
ing Delayed Ringing to each line/extension
key. Page 257
•
(1)
(2)
Y=01 Day Mode
My Line No. + + Key No.
0: Disabled
A
CM65
Ringer Tone
Pattern No.
Y=40: 0
Y=40: 1
Electra Terminal/
D
term
Series III
Elite Terminal/D
term
Series E/
D
term
Series i
0
Door Phone
Ringer Tone
1024 + 1285 [Hz]/
16 [Hz] Modulating Signal
1100 + 1400 [Hz]/
16 [Hz] Modulating Signal
1 Ringer Tone 1
480 + 606 [Hz]/
8 [Hz] Modulating Signal
520 + 660 [Hz]/
8 [Hz] Modulating Signal
2 Ringer Tone 2
600 + 700 [Hz]/
16 [Hz] Modulating Signal
660 + 760 [Hz]/
16 [Hz] Modulating Signal
3 Ringer Tone 3 1024 [Hz] Envelop 1100 [Hz] Envelop
4 Ringer Tone 4 500 [Hz] 540 [Hz]
5 Ringer Tone 5 1024 [Hz] 1100 [Hz]
6 Not used 1285 + 1024 [Hz] 1400 + 1100 [Hz]
7 Not used
480 + 606 [Hz]/
16 [Hz] Modulating Signal
520 + 660 [Hz]/
16 [Hz] Modulating Signal
CM90
,
B
FLEXIBLE RINGING ASSIGNMENT
