– 520 – NWA-008845-001 Rev.5.0
32ch1008.fm
To provide External Hold Tone Source through Pin JACK on the MP card:
DESCRIPTION DATA
Define the type of call to be provided with
Hold Tone.
NOTE: Set the JP1 switch on the MP card to
RIGHT position for using external
tone source.
•
(1)
(2)
Y=0
00: C.O. Line Call
01: Tie Line Call
02: Internal Call
1400: Hold Tone Source through MP card
START
CM48
END
MUSIC ON HOLD
To Next Page
