To provide the Message on Hold by the Digital Announcement Trunk (DAT):
DESCRIPTION DATA
Assign the Digital Announcement Trunk card
number to the required LEN.
NOTE 1: The Digital Announcement Trunk
card number must be assigned to the
first LEN (Level 0), the third LEN
(Level 2), the fifth LEN (Level 4) and
the seventh LEN (Level 6) of each
LT slot.
(1)
(2)
000-763: LEN
EB002-EB127: Digital Announcement
Trunk Card No.
For PIM0/1 : EB002-EB031
For PIM2/3 : EB032-EB063
For PIM4/5 : EB064-EB095
For PIM6/7 : EB096-EB127
NOTE 2: EB000 and EB001 are dedicated
to built-in Digital Announcement
Trunk of MP card.
Assign the Digital Announcement Trunk card
number to the required LEN.
[Series 3200 R6.2 software required]
NOTE 1: The Digital Announcement Trunk
card number must be assigned to the
first LEN (Level 0), the third LEN
(Level 2), the fifth LEN (Level 4) and
the seventh LEN (Level 6) of each
LT slot.
(1)
(2)
XX ZZZ: LEN
XX : 00-59: FP No.
ZZZ: 000-127: Port No.
EB002-EB127: Digital Announcement
Trunk Card No.
For FP No. 00 : EB002-EB031
For FP No. 01 : EB032-EB063
For FP No. 02 : EB064-EB095
For FP No. 03 : EB096-EB127
NOTE 2: EB000 and EB001 are dedicated
to built-in Digital Announcement
Trunk of MP card.
Assign Service Restriction Class A to required
stations.
•
(1)
(2)
Y=02
X-XXXXXXXX: Station No.
XX ZZ
XX: 00-15 : Service Restriction Class A
Allow Digital Announcement Trunk access
(Record/Replay/Delete) in Service Restriction
Class A assigned by CM12 Y=02.
•
(1)
(2)
Y=33
XX: Service Restriction Class A assigned
by CM12 Y=02
1 : Allow
Define the type of call to be provided with
Hold Message.
•
(1)
(2)
Y=0
00: C.O. Line Call
01: Tie Line Call
02: Internal Call
0500: Hold Message
START
CM10
CM14
CM12
CM15
CM48
A
JULY/01/2006
MUSIC ON HOLD
To Next Page
