Built-in SMDR on RS-232C Programming
DESCRIPTION DATA
Assign the system clock data. (1)
(2)
0: Calendar Year
2000-2099
(1)
(2)
1: Date
MM DD WW
MM : 01-12 (Month)
DD : 01-31 (Date)
WW: 00 (Sun)
01 (Mon)
02 (Tue)
03 (Wed)
04 (Thu)
05 (Fri)
06 (Sat)
(1)
(2)
2: Time
HH MM SS
HH : 00-23 (Hour)
MM: 00-59 (Minute)
SS : 00-59 (Second)
Specify SMDR terminal via RS port as the des-
tination to send a Built-in SMDR call informa-
tion.
[Series 3400 software required]
•
(1)
(2)
Y=01
05: Destination to send a Built-in SMDR
call information
0 : SMDR terminal via LAN port
1 : PMS via LAN port
7 : SMDR terminal via RS port
Specify the Message Format for Built-in
SMDR on RS-232C according to the SMDR
terminal specification.
[Series 3400 software required]
•
(1)
(2)
Y=01
07: Message Format for Built-in SMDR on
RS-232C
00 : Extended 2400 IMS Format
15 : Former 2400 IMS Format
START
CM02
CM04
A
STATION MESSAGE DETAIL RECORDING (SMDR)
PROGRAMMING
