DESCRIPTION DATA
NOTE: When the DESKCON is used to set hotel features, the Reset key should be assigned to one
of the feature keys (i.e key 21) in the Idle state mode.
A
CM90
L6 (12)
L5 (11)
L4 (10)
L3 (09)
L2 (08)
L1 (07)
0
89
6
3
5
2
1
4
7
#
SRC
(90)
DEST
(91)
(93)
(95)
Answer
(96)
Hold
(94)
Release
(97)
Cancel
Talk
Position Busy
Volume
Night
(15)
(01) (02) (03)
(04)
(13) (16) (17) (18) (92) (19) (20) (21)(14)
(24)(22)
(23)
LDN TIE Busy ATND NANS Recall
EMG BV TRKSL Call Park SC SVC
REC
Mute
PAGE
Start
Key No. Data Description (Key Label) Default Data
13
14
15
16
17
18
90
91
93
94
95
96
97
F6000
F6040
F6064
F6060
F6063
F6061
F6200
F6201
F6203
F6204
F6202
C.O. Incoming 0 (LDN)
Tie Line Incoming 0 (TIE)
Call Forwarding-Busy Line (Busy)
Operator Call (ATND)
Call Forwarding-No Answer (NANS)
Recall (Recall)
Source (SRC)
Destination (DEST)
Talk (Talk)
Hold (Hold)
Cancel (Cancel)
Answer (Answer)
Release (Release)
NONE
NONE
NONE
F6061 (Recall)
F6060 (Operator call)
F6000 (C.O. Incoming 0)
F6200 (Source)
F6201 (Destination)
NONE
F6204 (Hold)
F6202 (Cancel)
B
ATTENDANT CONSOLE
SN716 DESKCON
