DESCRIPTION DATA
When an External Announcement Machine is
required, assign the COT card and DK card to
required LEN.
[Series 3200 R6.2 software required]
NOTE 1: The DK card number must be as-
signed to the first LEN (level 0) and
the third LEN (Level 2).
(1)
(2)
XX ZZZ: LEN
XX : 00-59: FP No.
ZZZ: 000-127: Port No.
DB00-DB09: Interface card No. for Exter-
nal Announcement Machine
E800-E831 : DK Card
For FP No. 00: E800-E807
For FP No. 01: E808-E815
For FP No. 02: E816-E823
For FP No. 03: E824-E831
NOTE 2: Circuit No. 3 of E831 is used for
built-in External Equipment In-
terface of MP card by setting
CM44.
Specify ON/OFF condition for external relay/
external key on MP built-in DK00 card.
(1)
(2)
700
0 : ON (Ground Start)
OFF (Ground Off [Open])
1 : ON (Ground Off [Open])
OFF (Ground Start)
When the DAT is required, assign the DAT to
the required LEN.
To provide the restriction announcement for
Wake Up call setting, assign the following
DAT respectively.
• DAT for Wake Up message
• DAT for restriction announcement
NOTE 1: The DAT card number must be as-
signed to the first LEN (Level 0), the
third LEN (Level 2), the fifth LEN
(Level 4) and the seventh LEN (Lev-
el 6) of each LT slot.
(1)
(2)
000-763: LEN
EB002-EB127:
Digital Announcement Trunk Card No.
For PIM0/1: EB002-EB031
For PIM2/3: EB032-EB063
For PIM4/5: EB064-EB095
For PIM6/7: EB096-EB127
NOTE 2: EB000 and EB001 are dedicated
to built-in DAT of MP card.
B
CM14
CM08
CM10
C
JUNE/01/2007
HOTEL SYSTEM PROGRAMMING
AUTOMATIC WAKE UP
