blade and into the locked position. You will feel the blade pins
connect with the expansion module’s backplane as the blade locks
into place.
6 Remove the necessary number of the black rubber protective covers
from the ports on the FC I/O blades when you are ready to cable the
blade.
Note: The LEDs for the FC I/O blade are on the bottom of the
blade when the blade is correctly installed in the expansion
module.
