Getting Started
R&S
®
FSW
100User Manual 1173.9411.02 ─ 43
Figure 5-24: Tapping
Double-tapping
Tap the screen twice, in quick succession.
Double-tap a diagram or the window title bar to maximize a window in the display, or to
restore the original size.
Dragging
Move your finger from one position to another on the display, keeping your finger on
the display the whole time.
By dragging your finger over a table or diagram you can pan the displayed area of the
table or diagram to show results that were previously out of view.
Figure 5-25: Dragging
Pinching and spreading two fingers
Move two fingers together on the display (pinch) or move two fingers apart on the dis-
play (spread).
When you pinch two fingers in the display, you decrease the size of the currently dis-
played area, showing the surrounding areas previously out of view.
When you spread two fingers in the display, you increase the size of the currently dis-
played area, showing more details.
You can pinch or spread your fingers vertically, horizontally, or diagonally. The direction
in which you move your fingers determines which dimension of the display is changed.
Operating the Instrument
