General Instrument Setup
R&S
®
FSW
684User Manual 1173.9411.02 ─ 43
Table 12-1: ASCII file format for transducer factor files
File contents Description
Header data
sep=; Separator for individual values (required by Microsoft Excel, for
example)
Type;RS_TransducerFactor; Type of data
FileFormatVersion;1.00; File format version
Date;01.Oct 2006; Date of data set storage
OptionID;SpectrumAnalyzer Application the transducer factor was created for
Name;TestTDF1 Transducer factor name
Comment;Transducer for device A Description of transducer factor
XAxisScaling;LINEAR Scaling of x-axis linear (LIN) or logarithmic (LOG)
YAxisUnit;LEVEL_DB Unit of y values
YAxisScaleMode;ABSOLUTE Scaling of y-axis (absolute or relative)
NoOfPoints;5 Number of points the line is defined by
Data section for individual data points
100000000;-50.000000 x- and y-values of each data point defining the line
500000000;-30.000000
1000000000;0.000000
1500000000;-30.000000
2500000000;-50.000000
12.3.4 How to Configure the Transducer
Configuring the transducer is very similar to configuring transducer factors.
The transducer settings are defined in the "Transducer" dialog box which is displayed
when you press the [Setup] key and then select "Transducer".
Stored transducer settings
When storing and recalling transducer settings, consider the information provided in
"Saving and recalling transducer and limit line settings" on page 626.
The following tasks are described:
●
"How to find compatible transducer lines" on page 685
●
"How to activate and deactivate a transducer" on page 685
●
"How to edit existing transducer lines" on page 685
●
"How to copy an existing transducer line" on page 685
●
"How to delete an existing transducer line" on page 686
