R&S FSW Series User Manual

Common Analysis and Display Functions
R&S
®
FSW
512User Manual 1173.9411.02 ─ 43
Restores the original display, that is, the originally calculated displays for the entire
capture buffer, and closes all zoom windows.
Note: This function only restores graphically zoomed displays. Measurement zooms,
for which measurement settings were adapted, are recalculated based on the adapted
measurement settings. In this case, the zoomed display is maintained.
Remote command:
Single zoom:
DISPlay[:WINDow<n>][:SUBWindow<w>]:ZOOM[:STATe] on page 1122
Multiple zoom:
DISPlay[:WINDow<n>][:SUBWindow<w>]:ZOOM:MULTiple<zn>[:STATe]
on page 1124 (for each multiple zoom window)
Data shift (Pan)
Shifts the data to be evaluated in the result display (analysis region or hop/chirp) and
re-evaluates the new data. ALL result displays based on the same data (analysis
region or hop/chirp) are updated.
Currently, this function is only available in the Transient Analysis application.
Tip: Result tables are also re-evaluated for each data shift, which can take some time.
Close the result tables during a data shift/zoom to improve the screen update speed.
Data Zoom
Decreases the amount of data to be evaluated in the result display (analysis region or
hop/chirp) and re-evaluates the new data, thus enlarging the display of the remaining
data.
ALL result displays based on the same data (analysis region or hop/chirp) are updated.
Currently, this function is only available in the Transient Analysis application.
Tip: result tables are also re-evaluated for each data zoom, which can take some time.
Close the result tables during a data shift/zoom to improve the screen update speed.
9.2.3 How to Zoom Into a Diagram
The remote commands required to zoom into a display are described in Chap-
ter 14.8.1, "Zooming into the Display", on page 1121.
The following tasks are described here:
●
"To zoom into the diagram at one position" on page 513
●
"To return to original display" on page 513
●
"To zoom into multiple positions in the diagram" on page 513
●
"To maintain a zoomed display permanently" on page 514
For information on how to zoom into a diagram using touch gestures and change the
display permanently, see Chapter 5.4.5, "Touchscreen Gestures", on page 99.
Zoomed Displays
