Getting Started
R&S
®
FSW
63User Manual 1173.9411.02 ─ 43
SYNC TRIGGER
The SYNC TRIGGER connector can also be used to synchronize the reference fre-
quency on several devices (see Chapter 5.2.2.12, "SYNC TRIGGER OUTPUT/
INPUT", on page 60).
5.3 Trying Out the Instrument
This chapter introduces the most important functions and settings of the R&S FSW
step by step. The complete description of the functionality and its usage is given in the
R&S FSW User Manual. Basic instrument operation is described in Chapter 5.4, "Oper-
ating the Instrument", on page 81.
Prerequisites
●
The instrument is set up, connected to the mains system, and started up as descri-
bed in Chapter 5.1, "Preparing for Use", on page 24.
For these first measurements, you use the internal calibration signal, so you do not
need any additional signal source or instruments. Try out the following:
● Measuring a Basic Signal........................................................................................63
● Displaying a Spectrogram.......................................................................................65
● Activating Additional Measurement Channels.........................................................67
● Performing Sequential Measurements....................................................................70
● Setting and Moving a Marker.................................................................................. 71
● Displaying a Marker Peak List.................................................................................72
● Zooming into the Display.........................................................................................73
● Zooming into the Display Permanently................................................................... 76
● Saving Settings....................................................................................................... 79
● Printing and Saving Results....................................................................................80
5.3.1 Measuring a Basic Signal
We will start out by measuring a basic signal, using the internal calibration signal as
the input.
To display the internal 64 MHz calibration signal
1. Press the [PRESET] key to start out in a defined instrument configuration.
2. Press the [Setup] key on the front panel.
3. Tap the "Service + Support" softkey.
4. Tap the "Calibration Signal" tab.
Trying Out the Instrument
