14.5.6 Remote Commands for Noise Power Ratio (NPR) Measurements
● Activating an NPR Measurement..........................................................................902
● Configuring an NPR Measurement....................................................................... 902
● Configuring Signal Generator Control...................................................................905
● Retrieving Results from an NP Measurement.......................................................915
● Programming Example: Measuring the Noise Power Ratio..................................916
14.5.6.1 Activating an NPR Measurement
[SENSe:]NPRatio:STATe.................................................................................................902
[SENSe:]NPRatio:STATe <State>
Activates or deactivates the noise power ratio (NPR) measurement.
Parameters:
<State> ON | OFF | 0 | 1
OFF | 0
Deactivates the NPR measurement (returns to common fre-
quency sweep)
ON | 1
Activates the NPR measurement
*RST: 0
Example:
NPR:STAT ON
14.5.6.2 Configuring an NPR Measurement
[SENSe:]NPRatio:CHANnel:BWIDth................................................................................ 902
[SENSe:]NPRatio:CHANnel:INTegration:AUTO................................................................. 903
[SENSe:]NPRatio:CHANnel:INTegration:BWIDth...............................................................903
[SENSe:]NPRatio:CHANnel:INTegration:FREQuency:OFFSet............................................ 904
[SENSe:]NPRatio:NOTCh<notch>:BWIDth:RELative......................................................... 904
[SENSe:]NPRatio:NOTCh<notch>:BWIDth[:ABSolute].......................................................904
[SENSe:]NPRatio:NOTCh<notch>:COUNt........................................................................904
[SENSe:]NPRatio:NOTCh<notch>:FREQuency:OFFSet.................................................... 905
[SENSe:]NPRatio:CHANnel:BWIDth <Frequency>
Defines the channel bandwidth as an absolute value. Bandwidths covered by defined
notches are deducted from this value.
Parameters:
<Frequency> *RST: 72 MHz
Default unit: HZ
