82User Manual 1173.9411.02 ─ 43
Risk of touchscreen damage
Inappropriate tools or excessive force can damage the touchscreen.
Observe the following instructions when operating the touchscreen:
●
Never touch the screen with ball point pens or other sharp objects, use your fingers
instead.
As an alternative, you can use a stylus pen with a smooth soft tip.
●
Never apply excessive force to the screen. Touch it gently.
●
Never scratch the screen surface, for example with a finger nail.
●
Never rub the screen surface strongly, for example with a dust cloth.
For instructions on cleaning the screen, see Chapter 15.1, "Cleaning",
on page 1387.
● Understanding the Display Information...................................................................82
● Accessing the Functionality.....................................................................................92
● Changing the Focus................................................................................................96
● Entering Data.......................................................................................................... 97
● Touchscreen Gestures............................................................................................ 99
● Displaying Results.................................................................................................103
● Getting Help.......................................................................................................... 110
● Remote Control..................................................................................................... 112
5.4.1 Understanding the Display Information
The following figure shows a measurement diagram in Spectrum mode. All different
information areas are labeled. They are explained in more detail in the following sec-
tions.
