7.8.5 APD and CCDF Configuration
Configuration consists of the following settings:
●
Make sure the specified reference level is higher than the measured peak value
(see "Reference Level" on page 452).
● Basic Settings....................................................................................................... 297
● Gate Range Definition for APD and CCDF........................................................... 299
● Scaling for Statistics Diagrams............................................................................. 301
7.8.5.1 Basic Settings
Access: "Overview" > "Select Measurement" > "APD"/"CCDF" > "APD Config"/ "CCDF
Config"
Statistical Measurements (APD, CCDF)
