Measurements and Results
R&S
®
FSW
208User Manual 1173.9411.02 ─ 43
●
5GNR\UL\5GNR_UL_FR1_100MHz
●
5GNR\UL\5GNR_UL_FR2_100MHz
●
5GNR\UL\5GNR_UL_FR2_200MHz
LTE\DL
●
LTE\DL\LTE_DL_5MHZ.XML
●
LTE\DL\LTE_DL_10MHZ.XML
●
LTE\DL\LTE_DL_15MHZ.XML
●
LTE\DL\LTE_DL_20MHZ.XML
LTE\UL
●
LTE\UL\LTE_UL_5MHZ.XML
●
LTE\UL\LTE_UL_10MHZ.XML
●
LTE\UL\LTE_UL_15MHZ.XML
●
LTE\UL\LTE_UL_20MHZ.XML
WLAN
●
WLAN\802_11ac\802_11ac_20MHZ.XML
●
WLAN\802_11ac\802_11ac_40MHZ.XML
●
WLAN\802_11ac\802_11ac_80MHZ.XML
●
WLAN\802_11ac\802_11ac_160MHZ.XML
To load a stored measurement configuration, in the "General Settings" tab of the
"ACLR Setup" dialog box, select the "Manage User Standards" button to display the
"Manage" dialog box. Select the user standard file, then "Load".
The stored settings are automatically set on the R&S FSW and the measurement is
restarted with the new parameters.
For details, see Chapter 7.2.6.4, "How to Manage User-Defined Configurations",
on page 198.
7.3 Carrier-to-Noise Measurements
Measures the carrier-to-noise ratio. C/No measurements normalize the ratio to a 1 Hz
bandwidth.
● About the Measurement........................................................................................208
● Carrier-to-Noise Results........................................................................................209
● Carrier-to-Noise Configuration.............................................................................. 210
● How to Determine the Carrier-to-Noise Ratio....................................................... 212
7.3.1 About the Measurement
The largest signal in the frequency span is the carrier. It is searched when the C/N or
C/N
0
function is activated and is marked using a fixed reference marker ("FXD").
Carrier-to-Noise Measurements
