R&S FSW Series - Compensating for Frequency Response Using Touchstone Files (R&S FSW-K544)

Remote Commands
R&S
®
FSW
1271User Manual 1173.9411.02 ─ 43
String Unit
'DBUV/M' dBμV/m
(Requires R&S FSW-K54 (EMI measurements) option.)
'DBUA' dBμA
'DBUA/M' dBμA/m
(Requires R&S FSW-K54 (EMI measurements) option.)
'DBPW' dBpW
'DBPT' dBpT
MMEMory:LOAD<n>:TFACtor <FileName>
Loads the transducer factor from the selected file in .CSV format.
Suffix:
<n>
.
irrelevant
Parameters:
<FileName> String containing the path and name of the CSV import file.
Example:
MMEM:LOAD:TFAC 'C:\TEST.CSV'
Manual operation: See "Import" on page 683
MMEMory:STORe<n>:TFACtor <FileName>, <TransdName>
This command exports transducer factor data to an ASCII (CSV) file.
For details on the file format see Chapter 12.3.3, "Reference: Transducer Factor File
Format", on page 683.
Suffix:
<n>
.
irrelevant
Parameters:
<FileName> Name of the transducer factor to be exported.
<TransdName> Name of the transducer factor to be exported.
Example:
MMEM:STOR:TFAC 'C:\TEST', 'Transducer1'
Stores the transducer factor named "Transducer1" in the file
TEST.CSV.
Manual operation: See "Export" on page 683
14.10.4 Compensating for Frequency Response Using Touchstone files
(R&S FSW-K544)
If the Frequency Response Correction option (R&S FSW-K544) is installed, the
R&S FSW supports the use of Touchstone (.SnP) files, as well as additional frequency
response correction files in .fres format.
