Remote Commands

R&S

FSW

967User Manual 1173.9411.02 ─ 43

CALC:PSE:SUBR 10

//Sets 10 peaks per range to be stored in the list.

//--------------Performing the Measurement-----

INIT:SPUR; *WAI

//Performs a spurious emission measurement and waits until the sweep has finished.

//---------------Retrieving Results-------------

CALC:LIM1:FAIL?

//Queries the result of the check for limit line 1.

TRAC? SPUR

//Queries the peak list of the spurious emission measurement.

14.5.9 Analyzing Statistics (APD, CCDF)

All remote control commands specific to statistical measurements are described here.

● Activating Statistical Measurements..................................................................... 967

● Configuring Statistical Measurements...................................................................968

● Using Gate Ranges for Statistical Measurements................................................ 969

● Scaling the Diagram..............................................................................................971

● Performing a Statistical Measurement.................................................................. 974

● Retrieving Results.................................................................................................974

● Programming Example: Measuring Statistics....................................................... 975

14.5.9.1 Activating Statistical Measurements

The following commands activate statistical measurements.

CALCulate<n>:STATistics:APD[:STATe]............................................................................967

CALCulate<n>:STATistics:CCDF[:STATe]......................................................................... 967

CALCulate<n>:STATistics:APD[:STATe] <State>

This command turns the APD measurement on and off.

Suffix:

<n>

Window

Parameters:

<State> ON | OFF | 1 | 0

*RST: 0

Example:

CALC:STAT:APD ON

Switches on the APD measurement.

CALCulate<n>:STATistics:CCDF[:STATe] <State>

This command turns the CCDF on and off.
