R&S FSW Series User Manual

Measurements and Results
R&S
®
FSW
267User Manual 1173.9411.02 ─ 43
Saving the Result Summary (Evaluation List) to a File
Exports the Result Summary of the SEM measurement to an ASCII file for evaluation
in an external application. If necessary, change the decimal separator for evaluation in
other languages.
Define the filename and storage location in the file selection dialog box that is dis-
played when you select the "Save" function.
For details, see Chapter 7.6.8.2, "ASCII File Export Format (Spectrum Emission
Mask)", on page 279.
Remote command:
MMEMory:STORe<n>:LIST on page 1253
FORMat:DEXPort:DSEParator on page 1229
7.6.6 How to Perform a Spectrum Emission Mask Measurement
SEM measurements can be performed according to a specific standard or freely con-
figured. Configuration for signals with a regular channel definition can be configured
quickly and easily. Selecting the SEM measurement is a prerequisite for all other tasks.
For signals with multiple carriers, also in non-contiguous ranges, an SEM measure-
ment with multiple sub blocks can be configured.
For multi-standard radio SEM measurements, configuration for specified scenarios can
be done automatically.
The following tasks are described:
●
"To select an SEM measurement" on page 267
●
"To perform an SEM measurement according to a standard" on page 267
●
"To configure a user-defined SEM measurement" on page 267
●
"To perform an MSR SEM measurement" on page 269
●
"To perform a Multi-SEM measurement" on page 269
For remote operation, see Chapter 14.5.7.11, "Example: SEM Measurement",
on page 950.
To select an SEM measurement
► Press the [MEAS] key, then select the "Spectrum Emission Mask" measurement.
To perform an SEM measurement according to a standard
► Load the settings file as described in "How to load an SEM settings file"
on page 270 and start a measurement.
To configure a user-defined SEM measurement
1. Define the span of the signal you want to monitor in the general span settings.
Spectrum Emission Mask (SEM) Measurement
