Measurements and Results

R&S

FSW

279User Manual 1173.9411.02 ─ 43

Child node Attribute Value Parameter description Mand.

RFAttenuation Mode Manual | Auto "RF Att Mode" on page 253 Yes, if the Refer-

enceLevel child

node is used

Preamplifier

ON | OFF | 1 | 0 "Preamp" on page 254 Yes

7.6.8.2 ASCII File Export Format (Spectrum Emission Mask)

When trace data from an SEM measurement is exported, the data is stored in ASCII

format as described below. The first part of the file lists information about the signal

analyzer and the general setup.

File contents Explanation

File header

Type;FSW-26; Model

Version;1.00; Firmware version

Date;31.Mar 17; Storage date of data set

Mode;ANALYZER;SEM; Operating mode and measurement function

Center Freq;13250000000.000000;Hz X-axis settings

Freq Offset;0.000000;Hz

Span;25500000.000000;Hz

x-Axis;LIN;

Start;13237250000.000000;Hz

Stop;13262750000.000000;Hz

Level Offset;0.000000;dB Y-axis settings

Ref Position;100.000000;%

y-Axis;LOG;

Level Range;100.000000;dB

Trace settings

Trace Mode;CLR/WRITE;

Detector;RMS;

Sweep Count;0;

Trace 1:;

x-Unit;Hz;

y-Unit;dBm;

List evaluation settings

Margin;200; Peak List margin

Spectrum Emission Mask (SEM) Measurement
