Network and Remote Operation
R&S
®
FSW
771User Manual 1173.9411.02 ─ 43
Table 13-21: Instrument settings for emulation of 8566A/B, 8568A/B, 8594E; FSEA, FSEB, FSEM;
FSEK instruments
Model # of Trace
Points
Start Freq. Stop Freq. Ref Level Input Coupling
8566A/B 1001 2 GHz 22 GHz 0 dBm AC
8568A/B 1001 0 Hz 1.5 GHz 0 dBm AC
8560E 601 0 Hz 2.9 GHz 0 dBm AC
8561E 601 0 Hz 6.5 GHz 0 dBm AC
8562E 601 0 Hz 13.2 GHz 0 dBm AC
8563E 601 0 Hz 26.5 GHz 0 dBm AC
8564E 601 0 Hz 40 GHz 0 dBm AC
8565E 601 0 Hz 50 GHz 0 dBm AC
8594E 401 0 Hz 3 GHz 0 dBm AC
FSEA 500 0 Hz 3.5 GHz -20 dBm AC
FSEB 500 0 Hz 7 GHz -20 dBm AC
FSEM 500 0 Hz 26.5 GHz -20 dBm AC
FSEK 500 0 Hz 40 GHz -20 dBm AC
Note: The stop frequency indicated in the table may be limited to the corresponding
frequency of the R&S FSW, if required.
13.3 The IECWIN Tool
The R&S FSW is delivered with IECWIN installed, an auxiliary tool provided free of
charge by R&S. IECWIN is a program to send SCPI commands to a measuring instru-
ment either interactively or from a command script.
The R&S IECWIN32 tool is provided free of charge. The functionality may change in a
future version without notice.
IECWIN offers the following features:
Connection to instrument via several interfaces/protocols (GPIB, VISA, named pipe
(if IECWIN is run on the instrument itself), RSIB)
Interactive command entry
Browsing available commands on the instrument
Error checking following every command
Execution of command scripts
Storing binary data to a file
Reading binary data from a file
The IECWIN Tool
