R&S FSW Series - Remote Commands for EMI Measurements

Remote Commands
R&S
®
FSW
995User Manual 1173.9411.02 ─ 43
//Queries the measurement results.
//If the results are not accurate, change the position of the
//the temporary markers manually.
//----Changing the position of the temp markers-----
CALC:MARK:X 100MHZ
//Positions the reference marker on 100 MHz.
CALC:DELT2:X 5KHZ
//Positions delta marker 2 and 3 at a distance of 5 kHz to the reference marker.
CALC:DELT3:X 1KHZ
//Corrects the position of delta marker 3 by 1 kHz.
CALC:MARK:FUNC:MDEP:RES?
//Queries the measurement results for the repositioned markers.
14.5.14 Remote Commands for EMI Measurements
The following commands are required to perform EMI measurements in a remote envi-
ronment. This measurement requires the R&S FSW-K54 option.
The following tasks specific to the EMI application are described here:
● Activating EMI Measurement................................................................................ 995
● Configuring EMI Markers...................................................................................... 996
● Configuring the EMI Final Test..............................................................................997
● Configuring EMI Limit Lines.................................................................................. 998
● Controlling LISN....................................................................................................998
● Retrieving EMI Results........................................................................................1000
● Evaluating the Results........................................................................................ 1002
● Programming Example: EMI Measurement........................................................ 1002
14.5.14.1 Activating EMI Measurement
EMI measurement must be activated explicitely.
CALCulate<n>:DELTamarker<m>:FUNCtion:FMEasurement[:STATe]..................................995
CALCulate<n>:MARKer<m>:FUNCtion:FMEasurement[:STATe]......................................... 995
CALCulate<n>:DELTamarker<m>:FUNCtion:FMEasurement[:STATe] <State>
CALCulate<n>:MARKer<m>:FUNCtion:FMEasurement[:STATe] <State>
This command turns the EMI measurement marker functionality on and off.
Suffix:
<n>
.
irrelevant
<m> irrelevant
Parameters:
<State> ON | OFF | 1 | 0
Configuring and Performing Measurements
