Remote Commands
R&S
®
FSW
997User Manual 1173.9411.02 ─ 43
14.5.14.3 Configuring the EMI Final Test
The commands required to configure the EMI final test are described here.
Useful commands for configuring EMI final tests described elsewhere:
[SENSe:]BANDwidth[:RESolution]:TYPE on page 1032
[SENSe:]BANDwidth[:RESolution] on page 1031
DISPlay[:WINDow<n>][:SUBWindow<w>]:TRACe<t>:X:SPACing
on page 1025
Remote commands exclusive to configuring EMI final tests
CALCulate<n>:MARKer<m>:FUNCtion:FMEasurement:PEAKsearch:AUTO........................ 997
CALCulate<n>:DELTamarker<m>:FUNCtion:FMEasurement:PSEarch:AUTO...................... 997
CALCulate<n>:MARKer<m>:FUNCtion:FMEasurement:PSEarch:AUTO..............................997
CALCulate<n>:DELTamarker<m>:FUNCtion:FMEasurement:PEAKsearch:AUTO.................997
CALCulate<n>:DELTamarker<m>:FUNCtion:FMEasurement:DWELl...................................997
CALCulate<n>:MARKer<m>:FUNCtion:FMEasurement:DWELl.......................................... 997
CALCulate<n>:MARKer<m>:FUNCtion:FMEasurement:PEAKsearch:AUTO
<State>
CALCulate<n>:DELTamarker<m>:FUNCtion:FMEasurement:PSEarch:AUTO
<Mode>
CALCulate<n>:MARKer<m>:FUNCtion:FMEasurement:PSEarch:AUTO <State>
CALCulate<n>:DELTamarker<m>:FUNCtion:FMEasurement:PEAKsearch:AUTO
<Mode>
Suffix:
<n>
.
1..n
<m> 1..n
Parameters:
<Mode>
CALCulate<n>:DELTamarker<m>:FUNCtion:FMEasurement:DWELl <Time>
CALCulate<n>:MARKer<m>:FUNCtion:FMEasurement:DWELl <Time>
This command defines the dwell time during the final measurement.
Suffix:
<n>
.
irrelevant
<m> irrelevant
Parameters:
<Time> Range: 100 us to 100 s
*RST: 1 s
Default unit: s
Manual operation: See "Dwell Time" on page 348
Configuring and Performing Measurements
