R&S FSW Series User Manual

Common Analysis and Display Functions
R&S
®
FSW
510User Manual 1173.9411.02 ─ 43
Using the zoom area to restrict a peak search
The selected zoom area can be used to restrict the search range for a peak search,
but only in single zoom mode (see "Use Zoom Limits" on page 526).
9.2.2 Zoom Functions
Access: "Zoom" icons in toolbar
Single Zoom................................................................................................................510
Multi-Zoom.................................................................................................................. 510
Measurement Zoom.................................................................................................... 511
└ Level Lock.....................................................................................................511
└ X-Lock...........................................................................................................511
└ Y-Lock........................................................................................................... 511
└ Adapt Measurement to Zoom (selected diagram).........................................511
Restore Original Display..............................................................................................511
Data shift (Pan)....................................................................................................... 512
Data Zoom............................................................................................................... 512
Single Zoom
A single zoom replaces the current diagram by a new diagram which displays an
enlarged extract of the trace. This function can be used repetitively until the required
details are visible.
Remote command:
DISPlay[:WINDow<n>][:SUBWindow<w>]:ZOOM[:STATe] on page 1122
DISPlay[:WINDow<n>][:SUBWindow<w>]:ZOOM:AREA on page 1121
Multi-Zoom
In multiple zoom mode, you can enlarge several different areas of the trace simultane-
ously. An overview window indicates the zoom areas in the original trace, while the
zoomed trace areas are displayed in individual windows. The zoom area that corre-
sponds to the individual zoom display is indicated in the lower right corner, between the
scrollbars.
Remote command:
DISPlay[:WINDow<n>][:SUBWindow<w>]:ZOOM:MULTiple<zn>[:STATe]
on page 1124
DISPlay[:WINDow<n>][:SUBWindow<w>]:ZOOM:MULTiple<zn>:AREA
on page 1123
Zoomed Displays
