Getting Started
R&S
®
FSW
96User Manual 1173.9411.02 ─ 43
Figure 5-23: Context menu for channel bar setting
5.4.2.4 On-screen Keyboard
The on-screen keyboard is an additional means of interacting with the instrument with-
out having to connect an external keyboard.
The on-screen keyboard display can be switched on and off as desired using the "On-
Screen Keyboard" function key beneath the screen.
When you press this key, the display switches between the following options:
●
Keyboard displayed at the top of the screen
●
Keyboard displayed at the bottom of the screen
●
No keyboard displayed
You can use the TAB key on the on-screen keyboard to move the focus from one field
to another in dialog boxes.
5.4.3 Changing the Focus
Any selected function is always performed on the currently focused element in the dis-
play, e.g. a dialog field, diagram, or table row. Which element is focused is indicated by
Operating the Instrument
