//------------ Configuring List Evaluation-----------------
//Activate list evaluation, i.e. the peak is determined for each range
//after each sweep.
CALC:ESP:PSE:AUTO ON
//Define a peak threshold of 10 dB.
CALC:ESP:PSE:MARG 10dB
//------------ Managing Measurement Configurations----------
//Save the current configuration in a new file named '3GPP_UL_User'
//in the same directory so the standard is not overwritten.
ESP:PRES:STOR 'WCDMA\3GPP\UL\3GPP_UL_User.xml'
//------------ Performing the measurement-------------------
//One sweep
INIT:ESP
//------------ Checking the Results-------------------------
//Query the result of the limit check for all ranges.
CALC:LIM:FAIL?
//Query the peak for each range of the SEM measurement as a list.
TRAC:DATA? LIST
14.5.8 Measuring Spurious Emissions
The following commands are required to perform spurious emissions measurements.
● Initializing the Measurement................................................................................. 953
● Configuring a Sweep List...................................................................................... 954
● Configuring the List Evaluation............................................................................. 961
● Adjusting the X-Axis to the Range Definitions.......................................................963
● Performing a Spurious Measurement................................................................... 964
● Retrieving and Saving Settings and Results.........................................................964
● Programming Example: Spurious Emissions Measurement.................................964
14.5.8.1 Initializing the Measurement
Note that with the R&S FSW, the spurious measurement must be initialized before you
can start configuring the sweep list or list evaluation.
INITiate<n>:SPURious....................................................................................................953
INITiate<n>:SPURious
This command initiates a Spurious Emission measurement.
Suffix:
<n>
.
