Measurements and Results

R&S

FSW

292User Manual 1173.9411.02 ─ 43

7.7.6 Reference: ASCII Export File Format (Spurious)

The file has a header containing important parameters for scaling, several data sec-

tions containing the sweep settings per range, and a data section containing the peak

list.

The header data is made up of three columns, separated by ';', with the syntax:

Parameter name; numeric value; basic unit

File contents Explanation

File header

Type;FSW-26; Model

Version;1.00; Firmware version

Date;31.Mar 11; Storage date of data set

Mode;ANALYZER; SPURIOUS; Operating mode and measurement function

Center Freq;13250000000.000000;Hz X-axis settings

Freq Offset;0.000000;Hz

Span;26499982000.000000;Hz

x-Axis;LIN;

Start;9000.000000;Hz

Stop;8000000000.000000;Hz

Level Offset;0.000000;dB Y-axis settings

Ref Position;100.000000;%

y-Axis;LOG;

Level Range;100.000000;dB

Trace settings

Trace Mode;CLR/WRITE;

Sweep Count;1;

TRACE 1:

Trace Mode;CLR/WRITE;

x-Unit;Hz;

y-Unit;dBm;

List evaluation settings

Margin;6.000000;s Peak List margin

PeaksPerRange;25; Max. number of peaks per range to be detected

Values;3; Number of detected peaks

Spurious Emissions Measurement
