Remote Commands
R&S
®
FSW
1014User Manual 1173.9411.02 ─ 43
DISPlay:FORMat <Format>
This command determines which tab is displayed.
Parameters:
<Format> SPLit
Displays the MultiView tab with an overview of all active chan-
nels
(See Chapter 6.2, "R&S MultiView", on page 123).
SINGle
Displays the measurement channel that was previously focused.
*RST: SING
Example:
DISP:FORM SPL
DISPlay[:WINDow<n>]:SIZE
<Size>
This command maximizes the size of the selected result display window temporarily.
To change the size of several windows on the screen permanently, use the LAY:SPL
command (see LAYout:SPLitter on page 1018).
Suffix:
<n>
.
Window
Parameters:
<Size> LARGe
Maximizes the selected window to full screen.
Other windows are still active in the background.
SMALl
Reduces the size of the selected window to its original size.
If more than one measurement window was displayed originally,
these are visible again.
*RST: SMALl
Example:
DISP:WIND2:SIZE LARG
14.6.2 Working with Windows in the Display
The following commands are required to change the evaluation type and rearrange the
screen layout for a channel as you do using the SmartGrid in manual operation. Since
the available evaluation types depend on the selected application, some parameters
for the following commands also depend on the selected channel.
Note that the suffix <n> always refers to the window in the currently selected channel
(see INSTrument[:SELect] on page 828).
LAYout:ADD[:WINDow]?............................................................................................... 1015
LAYout:CATalog[:WINDow]?..........................................................................................1016
LAYout:IDENtify[:WINDow]?.......................................................................................... 1016
LAYout:MOVE[:WINDow].............................................................................................. 1017
LAYout:REMove[:WINDow]........................................................................................... 1017
