Remote Commands
R&S
®
FSW
1017User Manual 1173.9411.02 ─ 43
LAYout:MOVE[:WINDow] <WindowName>, <WindowName>, <Direction>
Setting parameters:
<WindowName> String containing the name of an existing window that is to be
moved.
By default, the name of a window is the same as its index. To
determine the name and index of all active windows in the active
channel, use the LAYout:CATalog[:WINDow]? query.
<WindowName> String containing the name of an existing window the selected
window is placed next to or replaces.
By default, the name of a window is the same as its index. To
determine the name and index of all active windows in the active
channel, use the LAYout:CATalog[:WINDow]? query.
<Direction> LEFT | RIGHt | ABOVe | BELow | REPLace
Destination the selected window is moved to, relative to the ref-
erence window.
Example:
LAY:MOVE '4','1',LEFT
Moves the window named '4' to the left of window 1.
Example:
LAY:MOVE '1','3',REPL
Replaces the window named '3' by window 1. Window 3 is
deleted.
Usage: Setting only
LAYout:REMove[:WINDow] <WindowName>
This command removes a window from the display in the active channel.
Setting parameters:
<WindowName> String containing the name of the window. In the default state,
the name of the window is its index.
Example:
LAY:REM '2'
Removes the result display in the window named '2'.
Usage: Setting only
LAYout:REPLace[:WINDow] <WindowName>,<WindowType>
This command replaces the window type (for example from "Diagram" to "Result Sum-
mary") of an already existing window in the active channel while keeping its position,
index and window name.
To add a new window, use the LAYout:ADD[:WINDow]? command.
Setting parameters:
<WindowName> String containing the name of the existing window.
By default, the name of a window is the same as its index. To
determine the name and index of all active windows in the active
channel, use the LAYout:CATalog[:WINDow]? query.
Configuring the Result Display
