R&S FSW Series User Manual

Remote Commands
R&S
®
FSW
1015User Manual 1173.9411.02 ─ 43
LAYout:REPLace[:WINDow].......................................................................................... 1017
LAYout:SPLitter............................................................................................................1018
LAYout:WINDow<n>:ADD?........................................................................................... 1019
LAYout:WINDow<n>:IDENtify?...................................................................................... 1020
LAYout:WINDow<n>:REMove........................................................................................1020
LAYout:WINDow<n>:REPLace...................................................................................... 1020
LAYout:ADD[:WINDow]? <WindowName>,<Direction>,<WindowType>
This command adds a window to the display in the active channel.
This command is always used as a query so that you immediately obtain the name of
the new window as a result.
To replace an existing window, use the LAYout:REPLace[:WINDow] command.
Query parameters:
<WindowName> String containing the name of the existing window the new win-
dow is inserted next to.
By default, the name of a window is the same as its index. To
determine the name and index of all active windows, use the
LAYout:CATalog[:WINDow]? query.
<Direction> LEFT | RIGHt | ABOVe | BELow
Direction the new window is added relative to the existing win-
dow.
<WindowType> text value
Type of result display (evaluation method) you want to add.
See the table below for available parameter values.
Return values:
<NewWindowName> When adding a new window, the command returns its name (by
default the same as its number) as a result.
Example:
LAY:ADD? '1',LEFT,MTAB
Result:
'2'
Adds a new window named '2' with a marker table to the left of
window 1.
Usage: Query only
Manual operation: See "Diagram" on page 502
See "Marker Table" on page 502
See "Marker Peak List" on page 502
See "Result Summary" on page 503
See "Spectrogram" on page 503
Table 14-3: <WindowType> parameter values for the Spectrum application
Parameter value Window type
DIAGram Diagram
MTABle Marker table
Configuring the Result Display
