Common Analysis and Display Functions

R&S

FSW

614User Manual 1173.9411.02 ─ 43

Remote command:

FORMat:DIMPort:TRACes on page 1147

File Explorer ← Import ASCII File to Trace ← Importing Traces

Opens the Microsoft Windows File Explorer.

Remote command:

not supported

9.6.3 How to Import Traces

Trace data that was stored during a previous measurement can be imported to the

Spectrum application, for example as a reference trace.

To import trace data

1. Press the [Trace] key.

2. Select "Trace Config" > "Trace / Data Export"/"Import".

3. Select "Import All Traces" to import traces for all the currently active traces, or

select a specific trace to be imported in "Import to Trace".

4. Select "Import ASCII File to Trace".

5. Select the file format in which the data is stored.

6. Select the file that contains the trace data.

7. Select "Select" to close the dialog box and start the import.

9.6.4 How to Export Trace Data and Numerical Results

The measured trace data and numerical measurement results in tables can be expor-

ted to an ASCII file. For each sweep point the measured trace position and value are

output.

The file is stored with a .DAT or .CSV extension. For details on the storage format see

Chapter 9.6.6, "Reference: ASCII File Export Format", on page 615.

For the results of a Spectrum Emission Mask (SEM) or Spurious Emissions measure-

ment, special file export functions are available, see Chapter 7.6.6.2, "How to Save

SEM Result Files", on page 271(SEM) and "Save Evaluation List" on page 290 (Spuri-

ous).

To export trace data and table results

1. Select [TRACE] > "Trace Config" > "Trace / Data Export" tab.

2. Select "Export all Traces and all Table Results" to export all available measurement

result data for the current application, or select a specific "Trace to Export".
