R&S FSW Series User Manual

Data Management
R&S
®
FSW
636User Manual 1173.9411.02 ─ 43
To recall settings automatically after preset or reboot
You can define the settings that are restored when you preset or reboot the instrument.
1. Configure the settings as required and save them as described in "To save configu-
rable instrument settings" on page 635.
2. In the "Save/Recall" menu, select "Startup Recall".
3. From the file selection dialog box, select the recall settings to restore.
4. Select "Select File".
5. Set "Startup Recall" to "On".
Now when you press the [PRESET] key or reboot the instrument, the defined set-
tings will be restored.
6. To restore the factory preset settings, set "Startup Recall" to "Off".
11.4 Import/Export Functions
Access: "Save"/ "Open" icon in the toolbar > "Import" / "Export"
The R&S FSW provides various evaluation methods for the results of the performed
measurements. However, you may want to evaluate the data with further, external
applications. In this case, you can export the measurement data to a standard format
file (ASCII or XML). Some of the data stored in these formats can also be re-imported
to the R&S FSW for further evaluation later, for example in other applications.
The following data types can be exported (depending on the application):
●
Trace data
●
Table results, such as result summaries, marker peak lists etc.
●
I/Q data
The following data types can be imported (depending on the application):
●
I/Q data
I/Q data can only be imported and exported in applications that process I/Q data, such
as the I/Q Analyzer or optional applications.
See the corresponding user manuals for those applications for details.
These functions are only available if no measurement is running.
In particular, if Continuous Sweep / Run Cont is active, the import/export functions are
not available.
Import..........................................................................................................................637
Export..........................................................................................................................637
└ Export Trace to ASCII File............................................................................ 637
└ File Type............................................................................................. 639
Import/Export Functions
