Measurements and Results
R&S
®
FSW
318User Manual 1173.9411.02 ─ 43
If harmonic measurement was performed in the time domain, this function adjusts the
reference level only.
Remote command:
CALCulate<n>:MARKer<m>:FUNCtion:HARMonics:PRESet on page 988
7.10.5 How to Determine the Harmonic Distortion
In Chapter 9.3.6, "Measurement Example: Measuring Harmonics Using Marker Func-
tions", on page 555, measuring harmonics was described using marker functions. This
task can be performed much simpler using the Harmonic Distortion measurement, as
described in the following procedure.
For remote operation, see Chapter 14.5.11.5, "Example: Measuring the Harmonic Dis-
tortion", on page 990.
1. Select the "Harmonic Distortion" measurement function from the "Select Measure-
ment" dialog box.
2. Define the number of harmonics to be determined using the "Number of Harmon-
ics" softkey.
3. Perform a sweep.
The trace for the determined harmonics are displayed in the diagram, separated by
red display lines. The measured power for each harmonic in relation to the funda-
mental is indicated in the result table.
4. If the signal changes significantly during or after the harmonics measurement, use
the "Adjust Settings" function to adjust the settings automatically and restart the
measurement.
7.11 Third Order Intercept (TOI) Measurement
The third order intercept point of the R&S FSW can be determined if a two-tone signal
with equal carrier levels is applied to the input.
CALCulate<n>:MARKer<m>:FUNCtion:TOI:RESult? on page 992
About the TOI Measurement.................................................................................319
TOI Basics.............................................................................................................319
TOI Results........................................................................................................... 323
TOI Configuration..................................................................................................324
How to Determine the Third Order Intercept.........................................................325
Measurement Example – Measuring the R&S FSW's Intrinsic Intermodulation... 325
Third Order Intercept (TOI) Measurement
