Page #988 background imageLoading...
Page #988 background image
Remote Commands
R&S
®
FSW
988User Manual 1173.9411.02 ─ 43
Remote commands exclusive to harmonic distortion measurements
CALCulate<n>:MARKer<m>:FUNCtion:HARMonics:BANDwidth:AUTO...............................988
CALCulate<n>:MARKer<m>:FUNCtion:HARMonics:NHARmonics......................................988
CALCulate<n>:MARKer<m>:FUNCtion:HARMonics:PRESet..............................................988
CALCulate<n>:MARKer<m>:FUNCtion:HARMonics:BANDwidth:AUTO <State>
This command selects the resolution bandwidth of the harmonic in respect to the band-
width of the first harmonic.
Suffix:
<n>
.
Window
<m> Marker
Parameters:
<State> ON | OFF | 0 | 1
OFF | 0
identical
ON | 1
a multiple
*RST: 1
Manual operation: See "Harmonic RBW Auto" on page 317
CALCulate<n>:MARKer<m>:FUNCtion:HARMonics:NHARmonics <NoHarmonics>
This command selects the number of harmonics that the R&S FSW looks for.
Suffix:
<n>
.
Window
<m> Marker
Parameters:
<NoHarmonics> Range: 1 to 26
*RST: 10
Manual operation: See "Number of Harmonics" on page 317
CALCulate<n>:MARKer<m>:FUNCtion:HARMonics:PRESet
This command initiates a measurement to determine the ideal configuration for the har-
monic distortion measurement.
The method depends on the span.
Frequency domain (span > 0)
Frequency and level of the first harmonic are determined and used for the mea-
surement list.
Time domain (span = 0)
The level of the first harmonic is determined. The frequency remains unchanged.
