General Instrument Setup
R&S
®
FSW
708User Manual 1173.9411.02 ─ 43
If a measurement is running, stop it by pressing the highlighted [Run Cont] or [Run
Single] key.
3. Select the [Setup] key.
4. Select the "System Config" softkey.
5. Select the "Firmware Update" tab.
6. In the file selection dialog box select the FSWSetup*.exe file.
"File Explorer": Instead of using the file manager of the R&S FSW firmware, you
can also use the Microsoft Windows File Explorer to manage files.
7. Select "Install" to start the update.
8. After the firmware update, the R&S FSW reboots automatically.
9. Depending on the previous firmware version, a reconfiguration of the hardware
might be required during the first startup of the firmware. The reconfiguration starts
automatically, and a message box informs you about the process. When the recon-
figuration has finished, the instrument again reboots automatically.
Note: Do not switch off the instrument during the reconfiguration process!
Now the firmware update is complete.
It is recommended that you perform a self-alignment after the update (see Chap-
ter 12.1.4, "How to Align the Instrument", on page 661).
12.6.5 General Configuration Settings
Access: [Setup] > "System Configuration" > "Config"
General system settings, for example concerning the initial behaviour of the R&S FSW
after booting, can also be configured.
Preset Mode................................................................................................................709
Out-of-range value behavior....................................................................................... 709
SecureUser Mode....................................................................................................... 709
└ Changing the password................................................................................ 709
Number block behavior............................................................................................... 710
System Configuration Settings
