Common Measurement Settings

R&S

FSW

474User Manual 1173.9411.02 ─ 43

●

When the average or peak values are determined for the new sweep, the results of

the previous sweeps in the spectrogram are also taken into account.

●

Off

The average or peak values are determined from the results of the newly swept

frames only.

Remote command:

CALCulate<n>:SPECtrogram:CONTinuous on page 1133

Frame Count ← Spectrogram Frames

Determines how many frames are plotted during a single sweep (as opposed to a con-

tinuous sweep). The maximum number of possible frames depends on the history

depth (see "History Depth" on page 599).

For more details see "Time Frames" on page 590.

Remote command:

CALCulate<n>:SPECtrogram:FRAMe:COUNt on page 1133

Clear Spectrogram ← Spectrogram Frames

Resets the spectrogram result display and clears the history buffer.

This function is only available if a spectrogram is selected.

Remote command:

CALCulate<n>:SPECtrogram:CLEar[:IMMediate] on page 1132

8.5.3 Reference: List of Available RRC and Channel Filters

For power measurement a number of especially steep-edged channel filters are availa-

ble (see the following table). The indicated filter bandwidth is the 3-dB bandwidth.

For RRC filters, the fixed roll-off factor (a) is also indicated.

The available Gaussian 3 dB sweep filters are listed in the R&S FSW data sheet.

Table 8-4: Filter types

Filter Bandwidth Filter Type Application

100 Hz CFILter

200 Hz CFILter

300 Hz CFILter

500 Hz CFILter

1 kHz CFILter

1.5 kHz CFILter

2 kHz CFILter

2.4 kHz CFILter SSB

Bandwidth, Filter and Sweep Configuration
