R&S FSW Series - Setting up Instrument Emulation

Remote Commands
R&S
®
FSW
1331User Manual 1173.9411.02 ─ 43
● Setting up Instrument Emulation.........................................................................1331
● Reference: GPIB Commands of Emulated HP Models.......................................1334
● Reference: Command Set of Emulated PSA Models..........................................1363
● Reference: Command Set of Emulated PXA Models..........................................1367
● Command Set for Analog Demodulation for Emulated PXA Models.................. 1369
● Command Set for Vector Signal Analysis (VSA) for Emulated R&S FSE Instru-
ments.................................................................................................................. 1370
14.13.1 Setting up Instrument Emulation
The following commands are required to set up the use of commands to emulate other
instruments.
Useful commands for emulating other instruments described elsewhere:
●
SYSTem:REVision:FACTory on page 1299
Remote commands exclusive to emulating other instruments:
SYSTem:HPCoupling................................................................................................... 1331
SYSTem:IFGain:MODE................................................................................................ 1332
SYSTem:HPADditional..................................................................................................1332
SYSTem:LANGuage.....................................................................................................1332
SYSTem:PREamp........................................................................................................1333
SYSTem:PSA:WIDeband..............................................................................................1333
SYSTem:REVision[:STRing]..........................................................................................1334
SYSTem:RSWeep........................................................................................................1334
SYSTem:HPCoupling <CouplingType>
Controls the default coupling ratios in the HP emulation mode for:
●
span and resolution bandwidth (Span/RBW) and
●
resolution bandwidth and video bandwidth (RBW/VBW)
For FSP (=FSW), the standard parameter coupling of the instrument is used. As a
result, in most cases a shorter sweep time is used than in case of HP.
This command is only available if a HP language is selected using SYSTem:LANGuage
on page 1332.
Parameters:
<CouplingType> HP | FSP
*RST: FSP
Example:
SYSTem:HPC HP
Manual operation: See "Coupling" on page 791
Emulating Other Instruments' Commands
