5.3.9 Saving Settings
To restore the results of our measurements later, we will store the instrument settings
to a file.
To save the instrument settings to a file
1. Tap the "Save" icon in the toolbar.
2. Press the keyboard key on the front panel to display the on-screen keyboard, as
you will have to enter text in the next step.
3. In the "Save" dialog box, tap the "File Name" field and enter MyMultiViewSetup
using the external or onscreen keyboard.
Keep the default "File Type" setting "Instrument with all Channels" to store the con-
figuration of all channels.
Figure 5-20: Saving the instrument settings to a file
4. Tap the "Save" button.
The file MyMultiViewSetup.dfl is stored in the default directory C:/R_S/
instr/user.
