R&S FSW Series - Measuring the Pulse Power

Remote Commands
R&S
®
FSW
1008User Manual 1173.9411.02 ─ 43
No Freq
[MHz]
Ref
Level
[dBm]
RF
Attenu-
ation
[dB]
El
Attenu-
ation
[dB]
Filter RBW VBW Meas
Time
Trigger
Level
1 935.2 0 10 --- Normal 1 MHz 3 MHz 440 µs 0
2 935.4 0 10 10 Channel 30 kHz 100 kHz 440 µs 0
3 935.6 0 10 20 Channel 30 kHz 100 kHz 440 µs 0
-----Measurement with synchronization via service request-----
*ESE 1
*SRE 32
// Configures the status reporting system to produce a service request.
LIST:POW:SET ON,ON,OFF,EXT,POS,10us,434us
//Turns on the list evaluation, configures the global list evaluation settings and
//evaluates the peak and RMS power.
LIST:POW
935.2MHZ,0,10,OFF,NORM,1MHZ,3MHZ,440us,0,
935.4MHZ,0,10,10,CFIL,30KHZ,100KHZ,440us,0,
935.6MHZ,0,10,20,CFIL,30KHZ,100KHZ,440us,0;
*OPC
//Defines a list with 3 entries and initiates the measurement with synchronization to the end.
//Analyzer produces a service request
//On service request:
SENS:LIST:POW:RES?
//Returns the results of the measurements, two for each frequency (peak and RMS power).
-----Initiliazing the measurement and querying results simultaneously-----
LIST:POW?
935.2MHZ,0,10,OFF,NORM,1MHZ,3MHZ,440us,0,
935.4MHZ,0,10,10,CFIL,30KHZ,100KHZ,440us,0,
935.6MHZ,0,10,20,CFIL,30KHZ,100KHZ,440us,0
//Defines a list with 3 entries, initiates the measurement and queries the results.
//Result example:
-28.3,-30.6,-38.1
14.5.16 Measuring the Pulse Power
All remote control commands specific to measuring the mean or peak pulse power
(e.g. bursts in various telecommunications standards) are described here. This mea-
surement is available via remote control only.
The Pulse Power measurement is a gated measurement that determines the power
over a particular number of pulses. The measurement is controlled by an external trig-
ger or the video signal. A separate trigger event is required for each burst included in
the measurement. In case of an external trigger source, the trigger level corresponds
to the TTL level. In case of a video signal, you can define any threshold.
Configuring and Performing Measurements
