R&S FSW Series User Manual

Remote Commands
R&S
®
FSW
1000User Manual 1173.9411.02 ─ 43
FOURphase
R&S ESH2-Z5: four phases (incl. protective earth) are controlla-
ble.
OFF
Turns off remote control of the LISN.
TWOPhase
R&S ESH3-Z5: two phases (incl. protective earth) are controlla-
ble.
*RST: OFF
Example: //Select LISN
INP:LISN:TYPE TWOP
Manual operation: See "LISN Type" on page 349
14.5.14.6
Retrieving EMI Results
The commands required to retrieve EMI measurement results are described here.
Useful commands for retrieving EMI measurement results described elsewhere:
●
CALCulate<n>:MARKer<m>:X on page 1156
CALCulate<n>:DELTamarker<m>:X on page 1154
●
CALCulate<n>:MARKer<m>:Y on page 1169
CALCulate<n>:DELTamarker<m>:Y on page 1169
Remote commands exclusive to retrieving EMI measurement results
CALCulate<n>:DELTamarker<m>:FUNCtion:FMEasurement:RESult?............................... 1000
CALCulate<n>:MARKer<m>:FUNCtion:FMEasurement:RESult?...................................... 1000
CALCulate<n>:DELTamarker<m>:FUNCtion:FMEasurement:LIMit<li>:LCONdition?........... 1001
CALCulate<n>:MARKer<m>:FUNCtion:FMEasurement:LIMit<li>:LCONdition?...................1001
CALCulate<n>:DELTamarker<m>:FUNCtion:FMEasurement:LIMit<li>:LDELta?................. 1001
CALCulate<n>:MARKer<m>:FUNCtion:FMEasurement:LIMit<li>:LDELta?.........................1001
CALCulate<n>:DELTamarker<m>:FUNCtion:FMEasurement:RESult? <Result>
CALCulate<n>:MARKer<m>:FUNCtion:FMEasurement:RESult? <Result>
This command queries the result of the EMI measurement at the marker position.
Suffix:
<n>
.
Window
<m> Marker
Return values:
<Result> Power level. The unit depends on the one you have currently
set.
Example:
CALC:MARK1:FUNC:FME:RES?
Queries the result of marker 1.
Usage: Query only
Configuring and Performing Measurements
