Remote Commands
R&S
®
FSW
1001User Manual 1173.9411.02 ─ 43
CALCulate<n>:DELTamarker<m>:FUNCtion:FMEasurement:LIMit<li>:
LCONdition? <Condition>
CALCulate<n>:MARKer<m>:FUNCtion:FMEasurement:LIMit<li>:LCONdition?
<Condition>
This command queries the condition of a marker position in relation to a certain limit
line.
Suffix:
<n>
.
Window
<m> Marker
<li> Limit line
Return values:
<Condition> 0
The marker has passed the limit check.
1
The marker is inside the margins of a limit line.
2
The marker has failed the limit check.
Example:
CALC:MARK1:FUNC:FME:LIM2:LCON?
Queries the condition of marker 1 in relation to limit line 2.
Usage: Query only
CALCulate<n>:DELTamarker<m>:FUNCtion:FMEasurement:LIMit<li>:LDELta?
CALCulate<n>:MARKer<m>:FUNCtion:FMEasurement:LIMit<li>:LDELta?
<Amplitude>
This command queries the vertical distance from the marker position to the limit line.
The unit is dB.
If the marker has been assigned to a different trace than the limit line, or if no limit ine
is defined for the marker position, the command returns -200.
Suffix:
<n>
.
Window
<m> Marker
<li> 1..n
Limit line
Return values:
<Amplitude> Vertical distance to the limit line in dB.
Example:
CALC:MARK3:FUNC:FME:LIM2:LDEL?
Queries the distance of marker 3 to the second limit line.
Usage: Query only
Configuring and Performing Measurements
