R&S FSW Series User Manual

Remote Commands
R&S
®
FSW
1156User Manual 1173.9411.02 ─ 43
Example:
CALC:MARK3 ON
Switches on marker 3.
Manual operation: See "Marker State" on page 343
See "Marker Type" on page 344
See "Select Marker" on page 345
CALCulate<n>:MARKer<m>:TRACe <Trace>
This command selects the trace the marker is positioned on.
Note that the corresponding trace must have a trace mode other than "Blank".
If necessary, the command activates the marker first.
Suffix:
<n>
.
Window
<m> Marker
Parameters:
<Trace> 1 to 6
Trace number the marker is assigned to.
Example: //Assign marker to trace 1
CALC:MARK3:TRAC 2
Manual operation: See "Assigning the Marker to a Trace" on page 344
CALCulate<n>:MARKer<m>:X <Position>
This command moves a marker to a specific coordinate on the x-axis.
If necessary, the command activates the marker.
If the marker has been used as a delta marker, the command turns it into a normal
marker.
Suffix:
<n>
.
Window
<m> Marker
Parameters:
<Position> Numeric value that defines the marker position on the x-axis.
The unit depends on the result display.
Range: The range depends on the current x-axis range.
Default unit: Hz
Example:
CALC:MARK2:X 1.7MHz
Positions marker 2 to frequency 1.7 MHz.
Manual operation: See "Marker 1/Marker 2/Marker 3/Marker 4" on page 324
See "Marker 1/Marker 2/Marker 3" on page 329
See "Marker Position X-value" on page 343
See "Marker Table" on page 502
See "Marker Peak List" on page 502
