Remote Commands
R&S
®
FSW
974User Manual 1173.9411.02 ─ 43
Parameters:
<Magnitude> The number is a statistical value and therefore dimensionless.
Range: 1E-5 to 1.0
*RST: 1.0
Example:
CALC:STAT:SCAL:Y:UPP 0.01
Manual operation: See "Y-Max/ Y-Min" on page 302
14.5.9.5 Performing a Statistical Measurement
The following commands are required to perform a statistical measurement:
INITiate<n>[:IMMediate] on page 836, see Chapter 14.5.1, "Performing Mea-
surements", on page 834
14.5.9.6 Retrieving Results
The following commands are required to retrieve the measurement results.
Useful commands for retrieving results described elsewhere:
CALCulate<n>:MARKer<m>:X on page 1156
Remote commands exclusive to statistical results
CALCulate<n>:STATistics:CCDF:X<t>?............................................................................974
CALCulate<n>:STATistics:RESult<res>?.......................................................................... 975
CALCulate<n>:STATistics:CCDF:X<t>? <Probability>
This command queries the results of the CCDF.
Suffix:
<n>
.
Window
<t> Trace
Query parameters:
<Probability> P0_01
Level value for 0.01 % probability
P0_1
Level value for 0.1 % probability
P1
P1: Level value for 1 % probability
P10
Level value for 10 % probability
Return values:
<CCDF Result>
Example:
CALC:STAT:CCDF:X1? P10
Returns the level values that are over 10 % above the mean
value.
Configuring and Performing Measurements
