General Instrument Setup
R&S
®
FSW
685User Manual 1173.9411.02 ─ 43
●
"How to configure a new transducer line" on page 686
●
"How to move the transducer line vertically or horizontally" on page 687
How to find compatible transducer lines
► In the "Transducer" dialog box, select the "View Filter" option: "Show Compatible".
All transducer lines stored on the instrument that are compatible to the current
measurement settings are displayed in the overview.
How to activate and deactivate a transducer
1. To activate a transducer select a transducer line in the overview and select the
"Active" setting for it.
The trace is automatically recalculated for the next sweep after a transducer line is
activated.
2. To deactivate a transducer line, deactivate the "Active" setting for it.
After the next sweep, the originally measured values are displayed.
How to edit existing transducer lines
Existing transducer line configurations can be edited.
1. In the "Transducer" dialog box, select the transducer line.
2. Select the "Edit" button.
3. Edit the line configuration as described in "How to configure a new transducer line"
on page 686.
4. Save the new configuration by selecting the "Save" button.
The trace is automatically recalculated for the next sweep if the transducer line is
active.
In order to store the changes to the transducer lines in a settings file, select the
"Save" icon in the toolbar.
(See Chapter 11.3, "Storing and Recalling Instrument Settings and Measurement
Data", on page 625).
How to copy an existing transducer line
1. In the "Transducer" dialog box, select the transducer line.
2. Select the "Copy" button.
The "Edit Transducer" dialog box is opened with the configuration of the selected
transducer.
3. Define a new name to create a new transducer with the same configuration as the
source line.
Transducers
