R&S FSW Series User Manual

Getting Started
R&S
®
FSW
51User Manual 1173.9411.02 ─ 43
Function key Assigned functions
MEAS Provides the measurement functions.
Measurement of multicarrier adjacent channel power (Ch Power ACLR)
Carrier to noise spacing (C/N C/N
0
)
Occupied bandwidth (OBW)
Spectrum emission mask measurement (Spectrum Emission Mask)
Spurious emissions (Spurious Emissions)
Measurement of time domain power (Time Domain Power)
Signal statistics: amplitude probability distribution (APD) and cumulative
complementary distribution function (CCDF)
Third-order intercept point (TOI)
AM modulation depth (AM Mod Depth)
MEAS CONFIG Used to define measurement configuration.
LINES Configures display lines and limit lines.
INPUT/OUTPUT Displays softkeys for input/output functions.
Measurement start functions
RUN SINGLE Starts a single new measurement (Single Sweep Mode).
RUN CONT Starts a continuous measurement (Continuous Sweep Mode).
Function execution (in navigation controls area)
UNDO Reverts last operation
REDO Repeats previously reverted operation.
5.2.1.10 Keypad
The keypad is used to enter alphanumeric parameters, including the corresponding
units (see also Chapter 5.4.4.2, "Entering Alphanumeric Parameters", on page 98). It
contains the following keys:
Table 5-3: Keys on the keypad
Type of key Description
Alphanumeric keys Enter numbers and (special) characters in edit dialog boxes.
Decimal point Inserts a decimal point "." at the cursor position.
Sign key Changes the sign of a numeric parameter. In the case of an alphanu-
meric parameter, inserts a "-" at the cursor position.
Unit keys (GHz/-dBm MHz/
dBm, kHz/dB and Hz/dB)
Adds the selected unit to the entered numeric value and complete the
entry.
In the case of level entries (e.g. in dB) or dimensionless values, all units
have the value "1" as multiplying factor. Thus, they have the same func-
tion as an [ENTER] key.
Instrument Tour
