Network and Remote Operation

R&S

FSW

760User Manual 1173.9411.02 ─ 43

STATus:QUEStionable:ACPLimit Register

The STATus:QUEStionable:ACPLimit register contains information about the results of

a limit check during ACLR measurements. A separate ACPLimit register exists for

each active channel.

You can read out the register with STATus:QUEStionable:ACPLimit:CONDition?

or STATus:QUEStionable:ACPLimit[:EVENt]?

Table 13-11: Meaning of the bits used in the STATus:QUEStionable:ACPLimit register

Bit No. Meaning

0 ADJ UPPer FAIL

This bit is set if the limit is exceeded in the upper adjacent channel

1 ADJ LOWer FAIL

This bit is set if the limit is exceeded in the lower adjacent channel.

2 ALT1 UPPer FAIL

This bit is set if the limit is exceeded in the upper 1st alternate channel.

3 ALT1 LOWer FAIL

This bit is set if the limit is exceeded in the lower 1st alternate channel.

4 ALT2 UPPer FAIL

This bit is set if the limit is exceeded in the upper 2nd alternate channel.

5 ALT2 LOWer FAIL

This bit is set if the limit is exceeded in the lower 2nd alternate channel.

6 ALT3 … 11 LOWer/UPPer FAIL

This bit is set if the limit is exceeded in one of the lower or upper alternate channels 3 … 11.

7 CACLR FAIL

This bit is set if the CACLR limit is exceeded in one of the gap channels.

8 GAP ACLR FAIL

This bit is set if the ACLR limit is exceeded in one of the gap channels.

9 to 14 Unused

15 This bit is always 0.

STATus:QUEStionable:EXTended Register

The STATus:QUEStionable:EXTended register contains further status information

not covered by the other status registers of the R&S FSW. A separate EXTended reg-

ister exists for each active channel.

You can read out the register with STATus:QUEStionable:EXTended:CONDition?

or STATus:QUEStionable:EXTended[:EVENt]?
