R&S FSW Series User Manual

Remote Commands
R&S
®
FSW
885User Manual 1173.9411.02 ─ 43
Parameters:
<Count> 0 | 1 | 2
Number of gap channels in the specified gap.
Parameters for setting and query:
<SBGaps> AB | BC | CD | DE | EF | FG | GH
Name of the gap, defined by the letters of the surrounding sub
blocks (e.g. "AB" for the gap between sub blocks A and B).
Example:
SENS:POW:ACH:GAP:MAN:CHAN:COUN:LOW BC, 2
Defines two lower gap channels in the gap between sub blocks
B and C.
Example: See "Example: Configuring and Performing an Asymmetrical
MSR ACLR Measurement" on page 895
Manual operation: See "Number of Lower Gap Channels" on page 191
[SENSe:]POWer:ACHannel:GAP<gap>:MANual:CHANnel:COUNt:UPPer
<SBGaps>, <Count>
[SENSe:]POWer:ACHannel:GAP<gap>:MANual:CHANnel:COUNt:UPPer?
<SBGaps>
Defines the number of upper gap channels in the specified gap.
Suffix:
<gap>
.
1 | 2
irrelevant
Parameters:
<Count> 0 | 1 | 2
Number of gap channels in the specified gap.
Parameters for setting and query:
<SBGaps> AB | BC | CD | DE | EF | FG | GH
Name of the gap, defined by the letters of the surrounding sub
blocks (e.g. "AB" for the gap between sub blocks A and B).
Example:
SENS:POW:ACH:GAP:MAN:CHAN:COUN:UPP BC, 1
Defines one upper gap channel in the gap between sub blocks B
and C.
Example: See "Example: Configuring and Performing an Asymmetrical
MSR ACLR Measurement" on page 895
Manual operation: See "Number of Upper Gap Channels" on page 191
[SENSe:]POWer:ACHannel:SPACing:GAP<gap>:MANual:LOWer <SBGaps>,
<Spacing>
[SENSe:]POWer:ACHannel:SPACing:GAP<gap>:MANual:LOWer? <SBGaps>
This command defines the distance from sub block to the specified lower gap channel.
Configuring and Performing Measurements
