180 Rockwell Automation Publication 2198-UM002L-EN-P - October 2021
Chapter 6 Configure and Start the Kinetix 5700 Drive System
Table 107 - Navigating the DC-bus Power Supply Menu
Menu/Sub Menu
Selections
Attributes Description Example Values
Module Info
Catalog number 2198-Pxxx
Firmware revision FW REV: 1.1.450167
Hardware revision HW REV: 1.1
Serial number SERIAL#: xxxxxxxxxxx
Diagnostics>
Converter
Diagnostics
Bus diagnostics
BUS VOLT: 0.0V
BUS CUR: 0.0A
Converter diagnostics
CONV UTIL: 0.7%
CONV TEMP: 31.7C
Shunt utilization SHUNT UTIL: 0.0%
Fault Log
Fault text
Fault code as listed in the Kinetix 5700 Fault Codes.xlsx file.
(1)
FLT S18 - CONV OVERTEMP FL
Fault details
The problem as reported in the Kinetix 5700 Fault Codes.xlsx file.
(1)
The measured converter temperature has exceeded the
factory set temperature limit.
Fault help
The Possible Solution as reported in the Kinetix 5700 Fault Codes.xlsx file.
(1)
Reduce the number of drives in the same bus group.
(1) For Kinetix 5700 fault code descriptions and possible solutions, see Kinetix 5700 Servo Drive Fault Codes, publication 2198-RD003
.
