Operation
Operating modes "Turtle" and "Rabbit"
152 / 476
ATTENTION
Hazard of heavy damage to the gear box.
Please observe the above hints in any case! Damage to the gearbox caused because
the above hints were not or only imprecisely complied with are excluded from any
guarantee or warranty!
The keys for switching between the operating modes may ONLY be used if the
machine is standing completely still (0.0 km/h). Additionally, sufficient pressure must
be present in the compressed air system. This is the case if the icon disappears
from the R-Touch. If you do not comply with this hint, then this may lead to destruction
of the gearbox.
6.7.2 Differential lock
The differential locks for the front and rear axles can be activated independently of
each other. The front axle is switched on/off by means of the key (3) and the rear axle
by means of the key (4) on the keypad I.
355540
3
4
